HOLZMANN D500VECO Wood Lathe (500 mm Between Centres, 300 W)

D500VECO

At 16.5 kg and 300 W, the HOLZMANN D500VECO is the one lathe of this group that a single person carries to the work and back. Speed is set by moving a belt across four fixed steps - 890, 1260, 1760 and 2600 min-1 - over 500 mm between centres and a 175 mm centre height, in an 890 x 325 x 414 mm body.

ფასი მოთხოვნით

The quoted price for the D500VECO moves mainly with order quantity, since school and training-workshop orders are usually placed in multiples, plus any chuck or additional chisels specified beyond the supplied set, and freight and customs clearance into Georgia.

ფასის მოთხოვნა

The entry point to the HOLZMANN lathe range

The HOLZMANN D500VECO is a compact wood lathe with 500 mm between centres, a 175 mm centre height and a 300 W motor, weighing 16.5 kg net. The D500VECO is the smallest and lightest machine in this selection and is built for hobby turning, school and training workshops, and joineries that need an occasional turned part rather than a production lathe. Total dimensions are 890 x 325 x 414 mm, so the D500VECO stores on a shelf and clamps to a bench when needed.

Four belt-change speeds

Speed on the D500VECO is set by moving the belt between four fixed steps: 890, 1260, 1760 and 2600 min-1. There is no electronic speed control on the D500VECO, so the machine has to be stopped and the belt repositioned to change speed. That is the honest trade for the price and the weight; turners who change speed constantly within a piece should look at a variable-speed model such as the D510F or the D460FXL instead.

Spindle thread and included accessories

The headstock of the D500VECO uses an M18 x 2.5 mm spindle thread, and HOLZMANN supplies an M33 x 3.5 adapter in the box so that standard M33 chucks and faceplates from the wider range can be fitted. Delivery also includes a Ø145 mm faceplate, a 300 mm tool rest, two chisels and a centre punch tip, which is enough to start turning without a separate tooling order.

Noise and working conditions

The D500VECO is quiet by lathe standards, rated at 84 dB(A) sound power and 71 dB(A) sound pressure, which makes it usable in a shared or domestic workshop where a 200 kg production lathe would not be.

What the D500VECO is not

The D500VECO has no copying attachment and no inverter drive, and its 300 W motor is sized for light passes in small sections. A workshop turning batches of identical table legs needs the DBK series; the D500VECO covers single pieces, repairs, handles, small bowls and training work.

ძირითადი მახასიათებლები

  • 16.5 kg net in an 890 x 325 x 414 mm body - carried one-handed and clamped to any bench, where the other D lathes need a fixed bench or their own stand
  • 300 W (S1) drive, the smallest motor in the D range, matched to light cuts in softwood and small blanks
  • Four fixed belt steps at 890, 1260, 1760 and 2600 min-1, changed by hand with the machine switched off
  • M18 x 2.5 mm headstock spindle - unique in this range - supplied with the M33 x 3.5 adapter so ordinary M33 chucks and faceplates still fit
  • 175 mm centre height, taller than the D510F and the D460FXL, over 500 mm between centres
  • The only lathe of the four with published noise figures: 84 dB(A) sound power, 71 dB(A) sound pressure
  • Delivered ready to turn with a 145 mm faceplate, a 300 mm tool rest, two chisels and a centre punch tip
  • No bed extension is offered for the D500VECO, so 500 mm between centres is a fixed ceiling

ტექნიკური მახასიათებლები

Motor power S1
300 W
Total dimensions
890 x 325 x 414 mm
Distance between centers
500 mm
Center height
175 mm
Lathe spindle speed
890 / 1260 / 1760 / 2600 min-1 (4 steps, belt change)
Head stock spindle
M18 x 2.5 mm (M33 x 3.5 adapter included)
Faceplate (included)
Ø 145 mm
Tool rest (included)
300 mm
Sound power level
84 dB(A)
Sound pressure level
71 dB(A)
Net weight
16.50 kg
Gross weight
19.50 kg
EAN code
9120132140540

უპირატესობები

  • Full accessory set included: M33 adapter, Ø145 mm faceplate, 300 mm tool rest, two chisels and a centre punch tip
  • Only 16.5 kg and 890 x 325 x 414 mm, so the D500VECO stores away between jobs
  • Quiet at 71 dB(A) sound pressure, usable in a shared or domestic workshop

გასათვალისწინებელი

  • Speed is changed by belt only — four fixed steps, no electronic variable-speed control
  • 300 W motor limits the D500VECO to light passes and small sections
  • No copying attachment and no bed extension, so capacity is fixed at 500 mm between centres

ხშირად დასმული კითხვები

What power supply does the HOLZMANN D500VECO need?
The HOLZMANN D500VECO is supplied as D500VECO_230V and runs from a standard 230 V single-phase socket with a 300 W motor. No three-phase 400 V connection is needed for the D500VECO, which is one reason it suits home workshops, schools and small joineries that cannot install industrial power.
What does the HOLZMANN D500VECO not do?
The HOLZMANN D500VECO does not copy from a master, has no electronic variable speed, and is not built for heavy production. Speed on the D500VECO is changed by moving a belt between four fixed steps, the 300 W motor is sized for light passes, and batch production of identical legs requires a copy lathe such as the DBK1300.
How are speeds changed on the D500VECO?
Speeds on the HOLZMANN D500VECO are selected by belt change between four fixed steps: 890, 1260, 1760 and 2600 min-1. The D500VECO must be switched off and the belt moved by hand to change speed, unlike the inverter-driven D510F, which is adjusted while running.
What chucks fit the D500VECO?
The HOLZMANN D500VECO has an M18 x 2.5 mm headstock spindle thread and is supplied with an M33 x 3.5 adapter, so standard M33 chucks and faceplates fit the D500VECO once the adapter is mounted. A Ø145 mm faceplate is already included in the delivery.
What is included with the D500VECO?
The HOLZMANN D500VECO is delivered with an M33 x 3.5 adapter, a Ø145 mm faceplate, a 300 mm tool rest, two chisels and a centre punch tip. That makes the D500VECO one of the few lathes in the range that can be put to work immediately without a separate tooling purchase.
How big a workpiece fits the D500VECO?
The HOLZMANN D500VECO takes workpieces up to 500 mm between centres with a 175 mm centre height above the bed. Anything longer than 500 mm does not fit the D500VECO and there is no bed extension for it, so chair legs and balusters need a larger lathe such as the D510F or the VD1100N.
What does the HOLZMANN D500VECO cost?
The HOLZMANN D500VECO is quoted rather than shelf-priced. Because the D500VECO already ships with a faceplate, tool rest, two chisels and a centre punch tip, the main things that move a D500VECO quotation are the number of machines ordered - schools and training workshops usually take several - any chuck added on top of the supplied M33 x 3.5 adapter, and freight and customs into Georgia.
How quickly can HOLZMANN D500VECO lathes be supplied?
The HOLZMANN D500VECO is built to order and the current lead time is confirmed on the quotation. At 19.5 kg gross each, a batch of D500VECO lathes for a classroom or training room ships as ordinary freight rather than as an oversize item, which keeps the transit part of the lead time simple.
Does a HOLZMANN D500VECO need any workshop preparation?
Very little. A HOLZMANN D500VECO needs a bench that will take an 890 x 325 mm footprint, a means of clamping or bolting the 16.5 kg machine down, and one 230 V socket. No three-phase supply, no compressed air and no extraction ducting are required for the D500VECO, which is why it suits homes, schools and shared workshops.
What should be budgeted alongside a HOLZMANN D500VECO?
The HOLZMANN D500VECO arrives with two chisels, so the usual additions are a fuller chisel set as skills develop, a scroll chuck fitted through the supplied M33 x 3.5 adapter, and a sharpening stone or grinder. Note that no bed extension exists for the D500VECO, so if work longer than 500 mm is expected the budget belongs on a larger lathe instead.
