OBF1200 — HOLZMANN OBF1200 Hand Router, 1200 W / 55 mm 1 / 4

HOLZMANN

HOLZMANN OBF1200 Hand Router, 1200 W / 55 mm

OBF1200

Where the TFM610V bolts a spindle under a table, the OBF1200 stays in the hand: a 1200 W class-II plunge router with variable speed from 11000 to 30000 min-1, 6 mm and 8 mm collets and 55 mm maximum milling depth. It weighs 4 kg net and arrives with rip fence, turret stop, guide sleeve, extractor adapter, chip shield and divider point.

ფასი მოთხოვნით

Price is driven by quantity, by whether a router bit set such as the OFS12 and the OFT102 table go on the same order, and by the freight and customs share of the consignment.

ფასის მოთხოვნა

What the HOLZMANN OBF1200 does

The HOLZMANN OBF1200 is a hand-held plunge router for grooving, rebating, edge profiling, template work and joint cutting. Milling depth on the OBF1200 reaches 55 mm and is adjusted steplessly, so the depth of a groove or a mortise is dialled to the workpiece rather than chosen from fixed steps. Speed on the OBF1200 runs from 11,000 to 30,000 min-1, which lets small profile cutters run fast for a clean finish while larger-diameter cutters are slowed to a safe rim speed. The OBF1200 takes both 8 mm and 6 mm shank cutters, covering the two shank sizes most European cutter sets are supplied in.

Who the OBF1200 suits

The HOLZMANN OBF1200 suits furniture workshops, joineries and door makers doing the shaping work that a stationary spindle moulder cannot reach: hinge and lock mortises in hung doors, worktop cut-outs, hand-stopped grooves, and template-guided repeat parts. At 4 kg net and 1200 W with appliance class II insulation, the OBF1200 is a machine one person carries to the workpiece. The OBF1200 is also the natural partner for the HOLZMANN ZFS600 dovetail jig, where the router supplies the power and the jig supplies the template.

How the OBF1200 differs from a stationary spindle moulder

The OBF1200 moves and the workpiece stays still; on a spindle moulder the workpiece is fed past a fixed tool. That makes the OBF1200 the right machine for short runs, site work, mortises and anything already assembled, and the wrong machine for running hundreds of metres of moulding, which belongs on a spindle moulder with a power feeder. Workshops typically own both and route with the OBF1200 anywhere a fence and feed table cannot be set up.

Delivery and working data

The HOLZMANN OBF1200 is delivered with a rip fence, turret stop, guide sleeve, extractor adapter, chip shield and divider point, so straight-line, circular and template routing are all covered out of the box. The OBF1200 is rated at 99 dB(A) sound power and 88 dB(A) sound pressure, with 7.08 m/s² handgrip vibration, so hearing protection is mandatory and working time should be managed.

ძირითადი მახასიათებლები

  • Hand-held plunge router - the machine the OFT102 table and ZFS600 dovetail jig are both built around
  • Speed range 11000 to 30000 min-1, the widest of the three routing products in this group
  • 55 mm maximum milling performance, steplessly set, against the 0-40 mm spindle stroke of the TFM610V
  • 6 mm and 8 mm collets only - 12 mm and 1/2 inch shanks do not fit
  • 1200 W S1 motor, 230 V / 50 Hz, appliance class II
  • Turret stop for stepped depth passes and a guide sleeve for template work such as the ZFS600
  • Divider point for circular routing, plus rip fence, extractor adapter and chip shield in the box
  • 4 kg net - the lightest of the group, so it goes to site as well as onto a table
  • Declared 99 dB(A) sound power, 88 dB(A) sound pressure, 7.08 m/s2 at the handgrip

ტექნიკური მახასიათებლები

Motor power S1
1200 W
Appliance class
II
Speed
11000-30000 min-1
Voltage
230V / 50Hz
Max. milling performance
55 mm
Chuck (collet) diameter
8 & 6 mm
Sound power level
99 dB(A)
Sound pressure level
88 dB(A)
Handgrip vibration
7.08 m/s²
Net weight
4 kg
Gross weight
4.50 kg
EAN code
9120058373510

უპირატესობები

  • 55 mm stepless milling depth with 11,000-30,000 min-1 variable speed covers grooving, rebating and profiling
  • Complete accessory set in the box: rip fence, turret stop, guide sleeve, chip shield, divider point and extractor adapter
  • 4 kg, 230V and class II - goes to the workpiece, including hung doors and fitted worktops

გასათვალისწინებელი

  • Collets are 8 mm and 6 mm only, so 12 mm and 1/2 inch shank cutters do not fit
  • No cutters are included in the delivery
  • 99 dB(A) sound power and 7.08 m/s² handgrip vibration mean hearing protection and managed working time

ხშირად დასმული კითხვები

Does the HOLZMANN OBF1200 need 230V or 400V?
The HOLZMANN OBF1200 is a 230V / 50Hz single-phase machine and there is no 400V three-phase version of the OBF1200. The 1200 W appliance class II motor of the OBF1200 plugs into any standard socket, unlike a stationary spindle moulder, which in most workshops is a 400V three-phase machine.
What does the HOLZMANN OBF1200 not do?
The HOLZMANN OBF1200 does not accept cutters with shanks other than 8 mm or 6 mm, and the OBF1200 cannot mill deeper than 55 mm. The OBF1200 has no table, fence system or power feed of its own, so it is not a substitute for a stationary spindle moulder on long production runs, and no cutters are listed as part of the delivery.
What cutter shank sizes fit the HOLZMANN OBF1200?
The HOLZMANN OBF1200 is supplied with collets for 8 mm and 6 mm cutter shanks. Cutters with 12 mm or 1/2 inch shanks will not fit the OBF1200, so check the shank size before ordering tooling.
Why does the HOLZMANN OBF1200 have a speed range of 11,000 to 30,000 min-1?
The HOLZMANN OBF1200 varies speed because rim speed rises with cutter diameter. Small profile and grooving cutters run near 30,000 min-1 on the OBF1200 for the cleanest finish, while larger-diameter cutters must be slowed towards 11,000 min-1 to stay within a safe and controllable cutting speed.
What is included with the HOLZMANN OBF1200?
The HOLZMANN OBF1200 is delivered with a rip fence, turret stop, guide sleeve, extractor adapter, chip shield and divider point. That covers straight fenced cuts, stepped depth passes, template routing and circular work with the OBF1200.
Can the HOLZMANN OBF1200 be used with the ZFS600 dovetail jig?
The HOLZMANN OBF1200 is a hand router with a guide sleeve, so it is the type of machine the ZFS600 dovetail jig is designed to be used with. The only condition is that the dovetail cutter shank matches one of the collets fitted to the OBF1200, which are 8 mm and 6 mm.
What decides the price of a HOLZMANN OBF1200?
The OBF1200 is quoted on enquiry, not sold at a fixed list price. The main drivers are quantity, whether cutters and a table are bought with it - the OFS12 12-piece bit set and the OFT102 router table are the usual companions to an OBF1200 - and the freight and customs share of the consignment. Cutters are the item most often forgotten from the budget, since none come with the OBF1200.
What is the lead time on an OBF1200?
The OBF1200 is built to order and the lead time is confirmed in writing with the quotation. We do not publish a fixed figure for the OBF1200, as it depends on HOLZMANN production and on when the shipment carrying it consolidates.
Does an OBF1200 need commissioning?
No. The OBF1200 plugs into a 230 V / 50 Hz socket and works out of the box. The one thing to settle in advance is table mounting: if the OBF1200 is to hang under an OFT102 router table, the base plate pattern of the OBF1200 has to be checked against that table's insert plate, because router bases differ between makers.
What tooling has to be budgeted with an OBF1200?
Router cutters are budgeted separately - no cutters are listed in the OBF1200 delivery. Check shank size before ordering any, because the OBF1200 takes 6 mm and 8 mm shanks only and will not accept 12 mm or 1/2 inch cutters. A guide bush set and a workshop vacuum for the extractor adapter are the other two items worth pricing with the OBF1200.
