SSAT2200 — HOLZMANN SSAT2200 Downdraft Sanding Table (2200 mm) 1 / 4

HOLZMANN

HOLZMANN SSAT2200 Downdraft Sanding Table (2200 mm)

SSAT2200

Two 1000 W fans, not one, are what the HOLZMANN SSAT2200 adds over the SSAT1000: 8000 m³/h across a 2200 x 600 mm top, filtered by four 395 x 495 x 24 mm front panels instead of two. Both Ø250 mm wheels run off a single 230 V / 50 Hz socket, sound pressure stays under 73,5 dB(A), and the table weighs 130 kg net.

ფასი მოთხოვნით

Price on the SSAT2200 is driven by the two-fan 8000 m³/h build and its four-filter block, the number of spare 395 x 495 x 24 mm filter sets taken with the table, and delivery and positioning of a 160 kg gross, 2250 mm crate inside the workshop.

ფასის მოთხოვნა

What the HOLZMANN SSAT2200 does

The HOLZMANN SSAT2200 is a self-contained sanding station: the table extracts sanding dust downwards and to the rear at 8000 m³/h using its own two 1000 W fans, so no external dust collector is needed at all. Air drawn off the 2200 x 600 mm work surface passes through four front filters of 395 x 495 x 24 mm and is returned filtered to the working space, which keeps the room breathable rather than dumping air outside. Dust settles in an extendable chip drawer at the front of the SSAT2200, pulled out and emptied without dismantling anything.

The work surface

The SSAT2200 table is laid out for real joinery work, not just small parts. Five metal insert plates give a support surface that does not damage the workpiece, thanks to plastic spacers, and a rubber-coated table protection allows scratch-free sanding of finished faces. Fold-away side panels extend the SSAT2200 for longer workpieces — door leaves, worktops, stair strings — and the whole table stands 850 mm high on a 2200 x 600 mm footprint at 130 kg net. Running noise is low for the airflow involved, at under 73.5 dB(A) sound pressure.

How the SSAT2200 differs from the SSAT1000 and SSAT150M

The three HOLZMANN sanding tables split by length and by whether they extract on their own. The SSAT2200 is 2200 mm long with two fans, 8000 m³/h and four filters; the HOLZMANN SSAT1000 is 1050 mm long with one 1000 W fan, 4000 m³/h and two filters, and weighs 68 kg against 130 kg. The HOLZMANN SSAT150M has no fan whatsoever and must be ducted into a separate collector. A door or furniture shop sanding full-size panels takes the SSAT2200; a small workshop sanding components takes the SSAT1000.

Power supply and installation

The SSAT2200 runs on 230 V / 50 Hz, so it plugs into an ordinary single-phase workshop socket despite its 8000 m³/h rating — no three-phase installation is required.

ძირითადი მახასიათებლები

  • 8000 m³/h drawn by two 1000 W fans - twice the airflow of the single-fan SSAT1000
  • 2200 x 600 x 850 mm top: a full door leaf or worktop lies flat in one span
  • Four front filters of 395 x 495 x 24 mm - double the SSAT1000's filter block
  • Two Ø250 mm fan wheels, both fed from one 230 V / 50 Hz socket
  • Sound pressure level below 73,5 dB(A)
  • 130 kg net / 160 kg gross, crated at 2250 x 690 x 730 mm
  • Five metal insert plates on plastic spacers plus rubber-coated protection, so finished faces can be laid down
  • Fold-away side panels extend support for longer workpieces
  • Extendable chip drawer at the front for emptying collected sanding dust

ტექნიკური მახასიათებლები

Motor power (S1)
2 x 1000 W
Voltage
230 V / 50 Hz
Total dimensions
2200 x 600 x 850 mm
Suction performance
8000 m³/h
Fan wheel diameter
Ø250 mm
Front filter size
4 x (395 x 495 x 24 mm)
Sound pressure level
< 73.5 dB(A)
Net weight
130 kg
Gross weight
160 kg
EAN code
9120132140717

უპირატესობები

  • 8000 m³/h of built-in extraction with no separate dust collector and no ducting
  • 2200 mm table with fold-away side panels handles doors, worktops and long stock
  • Quiet for its airflow at under 73.5 dB(A), and runs on ordinary 230 V single-phase power

გასათვალისწინებელი

  • Does not sand — an extraction table only; hand or orbital sanding is still manual work
  • 130 kg and a 2200 x 600 mm footprint permanently occupies a large bay
  • Four filters need regular cleaning or replacement, and dust is recirculated into the room rather than exhausted outside

ხშირად დასმული კითხვები

Does the HOLZMANN SSAT2200 need 400 V three-phase power?
No — the HOLZMANN SSAT2200 runs on 230 V / 50 Hz single-phase supply, supplied as SSAT2200_230V, and there is no 400 V version. Both of the SSAT2200's 1000 W fans are fed from that single-phase connection, so the table plugs into an ordinary workshop socket even though it moves 8000 m³/h.
What does the HOLZMANN SSAT2200 not do?
The HOLZMANN SSAT2200 does not sand — it is an extraction table, not a sanding machine. The SSAT2200 provides the surface and the airflow while the operator sands with hand tools or an orbital sander on top of it. The SSAT2200 is also not a general workshop dust collector: it cannot be hosed to a saw or planer, because its fans serve the table itself.
Does the HOLZMANN SSAT2200 need a separate dust collector?
No — the HOLZMANN SSAT2200 has two 1000 W fans and a four-filter block built in, extracting 8000 m³/h from the table without any external unit. The filtered air is returned to the workshop, so the SSAT2200 also needs no ducting to the outside.
Should I buy the HOLZMANN SSAT2200 or the SSAT1000?
Size the table to the workpiece and the filter block to the workload. The HOLZMANN SSAT2200 gives 2200 x 600 mm of top, 8000 m³/h from two 1000 W fans and four 395 x 495 x 24 mm filters at 130 kg net - the table for full door leaves and worktops. The SSAT1000 gives 1050 x 600 mm, 4000 m³/h from one fan and two filters at 68 kg, which suits component work and a shop with one metre of free wall. Note that HOLZMANN quotes a sound pressure level for the SSAT2200 (< 73,5 dB(A)) and a sound power level for the SSAT1000 (85 dB(A)), so the two cannot be ranked on noise from the published data.
How is the collected sanding dust emptied from the HOLZMANN SSAT2200?
The HOLZMANN SSAT2200 collects sanding dust in an extendable chip drawer at the front, which is pulled out and emptied. The SSAT2200's four front filters of 395 x 495 x 24 mm are also accessible from the front for cleaning and replacement.
Will the HOLZMANN SSAT2200 mark a finished surface?
The HOLZMANN SSAT2200 is built to avoid it: five metal insert plates with plastic spacers form the support surface and a rubber-coated table protection allows scratch-free working, so already-finished faces can be laid on the SSAT2200 during sanding.
What does a HOLZMANN SSAT2200 cost?
The HOLZMANN SSAT2200 is supplied by quotation. The price is set by the two-fan 8000 m³/h configuration and its four-filter block, how many spare 395 x 495 x 24 mm filter sets are taken with the table, and delivery and positioning of a 160 kg gross crate 2250 mm long inside the workshop. Because the SSAT2200 extracts on its own, there is no separate collector to add to the budget.
What is the lead time on a HOLZMANN SSAT2200?
The HOLZMANN SSAT2200 is built to order and the current lead time is confirmed at quotation. We check the factory position for the SSAT2200 when we price it, so you receive the delivery window and the figure in the same response.
What is involved in installing a HOLZMANN SSAT2200?
Installing a HOLZMANN SSAT2200 is mostly a siting and access exercise: a level floor run for the 2200 x 600 mm body with room along its length for the fold-away side panels, a single 230 V / 50 Hz supply for both 1000 W fans, and no ducting at all, since the SSAT2200 filters and returns air internally. Plan the position so the recirculated air is not directed at a finishing or spray area.
What running costs should be budgeted with an SSAT2200?
The recurring budget item on a HOLZMANN SSAT2200 is filters: four 395 x 495 x 24 mm front panels that load with sanding dust and need cleaning or replacement on a schedule set by how much you sand. Abrasives and the hand or orbital sanders used on the table are also separate, as the SSAT2200 supplies the surface and the airflow but no sanding tool.
