MZK 2800 PRESTIJ — Mizrak MZK 2800 PRESTIJ Sliding Table Panel Saw 1 / 4

MIZRAK

Mizrak MZK 2800 PRESTIJ Sliding Table Panel Saw

MZK 2800 PRESTIJ

Sitting between the 3200 mm and 2200 mm models, the MZK 2800 PRESTIJ offers 2800 mm of sliding table travel on the lightest mid-size frame in the line at 646 kg. The cutting head is unchanged from the longer PRESTIJ saws: 4 kW saw motor, 0.75 kW scorer, 80 mm depth at 90 degrees.

ფასი მოთხოვნით

Price on the MZK 2800 PRESTIJ is moved by the 2800 mm table length chosen instead of the 3200 mm or 2200 mm alternatives, the blade and scoring tooling package, the extraction unit specified, and delivery and installation - transport being simpler at 646 kg.

ფასის მოთხოვნა

What the MZK 2800 PRESTIJ does

The MZK 2800 PRESTIJ sizes board and squares solid timber over a 2800 mm carriage stroke, the middle capacity in the Mizrak PRESTIJ line. The 4 kW main motor turns blades from Ø250 x 30 mm to Ø300 x 30 mm at 4750 to 5250 rpm for 80 mm of depth at 90 degrees and 65 mm at 45 degrees. A separate 0.75 kW scoring motor spins a Ø125 x 20 mm blade at 7250 rpm to pre-cut the surface line, which is what keeps the bottom face of melamine board free of chipping. Crosscutting is set on a 1950 mm fence with stops adjustable from 0 to 3000 mm and angles to ±45 degrees.

Who the MZK 2800 PRESTIJ suits

The MZK 2800 PRESTIJ is a good match for a workshop with limited floor length that still cuts full sheets. At 646 kg the MZK 2800 PRESTIJ is the lightest of the mid-size PRESTIJ machines while keeping the same motors, tables and fences as the longer models, so cutting quality does not drop with the shorter stroke. Small and medium furniture makers, door shops and fit-out workshops are the typical buyers.

How the MZK 2800 PRESTIJ compares in the range

The MZK 2800 PRESTIJ shares its 4 kW saw motor, 0.75 kW scorer, 550 x 910 mm main table, 380 mm aluminium carriage and 8-shaft movement system with the MZK 3200 PRESTIJ and MZK 2200 PRESTIJ; only the stroke and the weight change. Against the MZK 3200 PRESTIJ the MZK 2800 PRESTIJ gives up 400 mm of travel and drops from around 700-790 kg to 646 kg. Against the MZK 2200 PRESTIJ the MZK 2800 PRESTIJ adds 600 mm of travel. None of the PRESTIJ machines has powered tilt – that is reserved for the SPECIAL models.

What is included

The MZK 2800 PRESTIJ is supplied with a 550 x 910 mm main table, a 380 x 540 mm side extension, a 785 x 970 mm rear extension and a 1200 mm rip fence. Machine height is 1400 mm, quoted noise is 80 dB and the extraction port sits 845 mm from the floor.

ძირითადი მახასიათებლები

  • 2800 mm sliding table with 2800 mm carriage travel
  • 380 mm aluminium carriage on an 8-shaft smooth movement system
  • 4 kW saw motor at 4750-5250 rpm with Ø250 x 30 mm to Ø300 x 30 mm blade capacity
  • 0.75 kW scoring motor spinning a Ø125 x 20 mm blade at 7250 rpm
  • 80 mm cut depth at 90 degrees, 65 mm at 45 degrees
  • 1950 mm sliding fence with a 0-3000 mm stop range and ±45 degree angle setting
  • 646 kg net weight - the lightest mid-size machine in the PRESTIJ line

ტექნიკური მახასიათებლები

Saw Blade Outer and Inner Diameter (Min - Max)
Ø250 x 30 mm - Ø300 x 30 mm
Max. Cutting Depth (at 90º)
80 mm
Max. Cutting Depth (at 45º)
65 mm
Noise Level
80 dB
Saw Blade Speed
4750 - 5250 RPM
Saw Motor Power
4 kW
Table Dimensions
550 x 910 mm
Side Table Extension Dimensions
380 x 540 mm
Rear Table Extension Dimensions
785 x 970 mm
Rip Fence Length on Table
1200 mm
Sliding Table Length
2800 mm
Sliding Table Travel Distance
2800 mm
Sliding Table Fence Angle (Right-Left)
0-45º both directions
Aluminum Carriage Width
380 mm
Sliding Table Fence Length
1950 mm
Sliding Table Fence Angle (Right-Left)
±45º
Sliding Table Fence Stop Range
0 - 3000 mm
Scoring Saw Blade Diameter (Outer/Inner)
Ø125 x 20 mm
Scoring Saw Speed
7250 RPM
Scoring Saw Motor Power
0.75 kW
Dust Extraction Port Height from Floor
845 mm
Machine Height
1400 mm
Net Weight
646 kg

უპირატესობები

  • Same 4 kW motor, scoring unit and table set as the larger PRESTIJ saws in a shorter, cheaper machine
  • 646 kg is the easiest weight in the mid-range to move, site and level
  • Simple mechanical adjustment means fewer electronic parts to fail or service

გასათვალისწინებელი

  • 2800 mm stroke will not carry the longest boards in one pass
  • Blade tilt and blade height are both manual
  • No extractor supplied and no published supply voltage - both need confirming before commissioning

ხშირად დასმული კითხვები

What electrical supply does the MZK 2800 PRESTIJ need?
The MZK 2800 PRESTIJ combines a 4 kW saw motor with a 0.75 kW scoring motor, but the supplier's technical table for the MZK 2800 PRESTIJ does not state supply voltage or total connected load. Confirm the electrical requirement with us before installation.
Can the MZK 2800 PRESTIJ cut a full sheet?
The MZK 2800 PRESTIJ has 2800 mm of sliding table travel, so panel length is limited by that stroke. Where boards are longer than the MZK 2800 PRESTIJ carriage can carry in one pass, the MZK 3200 PRESTIJ or MZK 3800 PRESTIJ is the correct machine.
How heavy is the MZK 2800 PRESTIJ and what does that mean for installation?
The MZK 2800 PRESTIJ has a net weight of 646 kg, so it needs a solid, level floor and mechanical lifting to position. Plan the delivery route into the workshop for the MZK 2800 PRESTIJ before the machine arrives.
What tooling does the MZK 2800 PRESTIJ take?
The MZK 2800 PRESTIJ takes main blades between Ø250 x 30 mm and Ø300 x 30 mm and a Ø125 x 20 mm scoring blade. The supplier does not list an included blade set for the MZK 2800 PRESTIJ, so agree the tooling at the point of order.
Does the MZK 2800 PRESTIJ include dust extraction?
No. The MZK 2800 PRESTIJ provides a connection point 845 mm above the floor but no extractor unit. The MZK 2800 PRESTIJ has to be linked to a separate workshop extraction system.
What does the MZK 2800 PRESTIJ not do?
The MZK 2800 PRESTIJ has no powered tilt, no programmed cutting and no automatic panel feed. Both the 45 to 90 degree angle and the blade height on the MZK 2800 PRESTIJ are set by hand, and every cut is operator-driven.
How much does the MZK 2800 PRESTIJ cost?
The MZK 2800 PRESTIJ is supplied on quotation rather than at a published price. The cost of an MZK 2800 PRESTIJ depends on the 2800 mm table length chosen over the neighbouring 3200 mm and 2200 mm models, the blade and scoring tooling package, whether extraction is supplied with the machine, and delivery and installation. Tell us your floor length and board sizes for a quotation.
How long does it take to get an MZK 2800 PRESTIJ?
The MZK 2800 PRESTIJ is manufactured to order, so the lead time for an MZK 2800 PRESTIJ is confirmed at quotation against the current schedule rather than promised in advance. Raise any fixed commissioning date when you enquire.
What preparation does installing an MZK 2800 PRESTIJ need?
Installing an MZK 2800 PRESTIJ needs a level load-bearing floor with clear run for the 2800 mm carriage, a three-phase connection for the 4 kW saw and 0.75 kW scoring motors, and extraction ducted to the port 845 mm above the floor. At 646 kg the MZK 2800 PRESTIJ is straightforward to position, and levelling and commissioning are quoted with the machine.
Which running costs sit outside the MZK 2800 PRESTIJ machine price?
Blades and extraction sit outside the MZK 2800 PRESTIJ machine price: main blades from 250 x 30 mm to 300 x 30 mm, 125 x 20 mm scoring blades, and a dust extractor, none of which are listed in the supplier specification for the MZK 2800 PRESTIJ. Sharpening cycles should be budgeted as an ongoing cost.
