HOLZMANN OSS200 Oscillating Spindle Sander (400 V, 300 mm roller)
OSS200
A second motor is the dividing line: beside the 750 W spindle drive of the HOLZMANN OSS200 sits a dedicated 370 W motor working a 140 mm oscillation stroke. The OSS200 is the only 400 V machine in this range, holds 300 to 950 min-1 steplessly, arrives with a 300 mm roller of 20 K120 lamellas and weighs 114 kg.
What moves the OSS200 price is the number of spare 300 mm lamella rollers and grits ordered with it, whether the workshop's 400 V three-phase supply and board already reach the machine position, the extractor chosen for the 120 mm port, and delivery and positioning of a 114 kg stationary machine.
ფასის მოთხოვნაWhat the HOLZMANN OSS200 does
The HOLZMANN OSS200 is a stationary oscillating spindle sander for curved and profiled wooden parts. Two motors do separate jobs on the OSS200: a 750 W motor turns the spindle at a steplessly adjustable 300 to 950 rpm, while a 370 W motor drives the 140 mm oscillation stroke that spreads wear along the abrasive and prevents burn marks and sanding lines. The working table sits at 773 mm and a workpiece arm supports long parts against the roller.
Which workshops the OSS200 suits
The HOLZMANN OSS200 suits door manufacturers, stair builders and furniture workshops that sand shaped edges in series rather than one at a time. The 300 mm sanding roller supplied with 20 K120 lamellas covers tall workpiece edges in one setting, and the low measured sound pressure of under 70 dB(A) makes the OSS200 tolerable to stand at for a full shift. Net weight is 114 kg on a 760 x 680 x 1100 mm footprint, so the OSS200 is a fixed workshop machine, not a bench tool that is stored away.
OSS200 next to the OSS75A and OBS100A
The HOLZMANN OSS200 sits well above the bench-top HOLZMANN OSS75A and OBS100A. Those two run 450 W motors on 230 V and weigh 9 and 12.5 kg with sanding sleeves from 15 to 78 mm diameter, which suits small radii and occasional work. The OSS200 is a 400 V three-phase machine with a 300 mm lamella roller, adjustable speed and a 120 mm extraction port, built for continuous production. Workshops without a three-phase supply should take the OSS75A or OBS100A instead.
Delivery
The HOLZMANN OSS200 is delivered with the 300 mm sanding roller fitted with 20 K120 sanding lamellas. A dust extractor for the 120 mm port is ordered separately.
ძირითადი მახასიათებლები
- Dedicated 370 W oscillation motor alongside the 750 W spindle motor
- Oscillation stroke of 140 mm
- Sanding speed stepless from 300 to 950 min-1
- Sanding roller of 300 mm diameter with 20 K120 lamellas included
- 400 V / 50 Hz three-phase - the only three-phase machine in this range
- Stationary build with workpiece arm; table height 773 mm
- Dust extraction port of 120 mm diameter
- Sound pressure level below 70 dB(A); 114 kg net, 760 x 680 x 1100 mm
ტექნიკური მახასიათებლები
- Motor power S1
- 750 | 370 W
- Voltage
- 400 V / 50 Hz
- Speed
- 300 - 950 min-1
- Table height
- 773 mm
- Dust collector port
- 120 mm
- Total dimensions
- 760 x 680 x 1100 mm
- Sound pressure level
- <70 dB(A)
- Net weight
- 114 kg
- Gross weight
- 134 kg
- EAN code
- 9120132141806
უპირატესობები
- Separate 750 W spindle motor and 370 W oscillation motor for even, powerful removal
- Stepless 300 to 950 min-1 speed control suits different woods and abrasives
- Low measured sound pressure below 70 dB(A) for all-day production work
გასათვალისწინებელი
- 400 V three-phase only, so there is no option for a single-phase workshop
- 114 kg and 760 x 680 x 1100 mm make the OSS200 a permanently installed machine
- Extraction on the 120 mm port is not included and must be bought separately
