HOLZMANN ZS400U Mini Wide Belt Sander (400 mm)
ZS400U
The HOLZMANN ZS400U is a 230 V mini wide belt sander with a 400 mm sanding width, a 132 mm sanding drum and a stepless 0-3 m/min feed, built for calibrating glued-up panels, drawer fronts and door blanks. Workpieces from 5 to 130 mm thick pass through the ZS400U on a cast iron sanding unit weighing 96 kg net.
Price moves with the ZS400U machine configuration, freight and customs clearance for a 144 kg gross shipment into Georgia, and the extras added - abrasive belt sets, a dust extractor sized for the 400 mm drum, delivery and on-site commissioning.
ფასის მოთხოვნაWhere the HOLZMANN ZS400U fits in a joinery shop
Calibrating glued-up panels is the job the ZS400U is built for. A 132 mm sanding drum covers the full 400 mm working width, and the powered table carries the workpiece through at a feed rate set steplessly between 0 and 3 m/min, so a panel that would chatter under planer knives leaves the machine flat and ready for finish grits.
Thickness range of 5 to 130 mm
Thickness capacity is where the ZS400U outreaches the wider ZS560U. Stock from 5 mm board up to 130 mm door blanks and stair components passes under the drum, which puts solid joinery parts inside the working range instead of sheet-thickness panels alone.
Drive, feed and abrasives
The ZS400U stays on a single-phase supply: 2250 W in S6 duty and 1500 W in S1 duty at 230 V, which avoids a three-phase installation in a small shop. Feed speed is set by potentiometer rather than stepped pulleys, so the rate can be trimmed to grit and species instead of being fixed. The sanding carpet is tensioned by a spring system, and commercially available sanding belts fit the drum, which keeps consumables easy to re-order in Georgia.
Frame and workpiece support
Rigidity comes from the cast iron construction of the sanding unit and 96 kg of machine mass. Front and rear table extensions carry long components into and out of the drum, which matters more on a 400 mm calibrating sander than extra motor power would.
Planning the installation
Extraction and handling belong in the plan before delivery. The HOLZMANN ZS400U ships at 1360 x 640 x 940 mm and 144 kg gross, declares a sound power level of 96 dB(A) and a sound pressure level of 87 dB(A), and produces continuous fine dust that needs a dedicated extractor – equipment that is not part of the machine unless it is written into the quotation.
Requesting a quote for the ZS400U
Pricing for the ZS400U as a Georgian import follows the machine configuration, freight and customs clearance for a 144 kg gross shipment, and the abrasives, extraction and commissioning added to the order. Send the panel widths, thicknesses and species handled in your shop, and the ZS400U will be quoted with the belt sets and delivery terms to match.
ძირითადი მახასიათებლები
- 400 mm maximum sanding width worked by a single 132 mm sanding drum, calibrating the full panel width in one pass
- Stepless feed from 0 to 3 m/min set by potentiometer, so the feed rate is matched to grit, species and depth of cut
- Workpiece capacity from 5 mm to 130 mm thickness, covering thin board through solid door blanks and stair parts
- 2250 W S6 / 1500 W S1 motor on a 230 V single-phase supply, with no three-phase connection required
- Cast iron construction in the sanding unit and 96 kg net machine weight to damp vibration during calibration
- Spring-adjusted carpet tension holding commercially available sanding belts, keeping consumables easy to re-order
- Front and rear table extensions supporting long workpieces entering and leaving the 400 mm sanding zone
- Declared noise emission of 96 dB(A) sound power and 87 dB(A) sound pressure for workshop noise assessment
ტექნიკური მახასიათებლები
- Motor power (S6)
- 2250 W
- Motor power (S1)
- 1500 W
- Voltage
- 230 V
- Feed speed
- 0-3 m/min (stepless)
- Max. sanding width
- 400 mm
- Sanding drum diameter
- 132 mm
- Max. workpiece thickness
- 130 mm
- Min. workpiece thickness
- 5 mm
- Sound power level
- 96 dB(A)
- Sound pressure level
- 87 dB(A)
- Net weight
- 96 kg
- Gross weight
- 144 kg
- Packaging length
- 940 mm
- Packaging width
- 640 mm
- Packaging height
- 1360 mm
- EAN code
- 9120039908182
უპირატესობები
- Handles 130 mm thick workpieces, the deepest capacity of the two HOLZMANN mini wide belt sanders, so solid door blanks and stair components stay in scope
- Runs from a 230 V single-phase supply at 2250 W S6, letting a small shop add panel calibrating without installing three-phase power
- Uses commercially available sanding belts with spring-based carpet tensioning, keeping abrasive re-ordering simple and cheap over the life of the machine
გასათვალისწინებელი
- The 400 mm sanding width caps panel size; wider tops must be flipped and run in two passes or moved to the 560 mm ZS560U
- One 132 mm drum only, with no second head or platen unit, so the ZS400U calibrates but does not replace a final finish-sanding operation
- At 96 kg net and 144 kg gross the ZS400U needs a pallet truck and two people to place, and neither dust extraction nor abrasive sets is part of the machine
