10015511 — HOLZMANN 10015511 Carbide Round Turning Tip Ø 6 mm 1 / 3

HOLZMANN

HOLZMANN 10015511 Carbide Round Turning Tip Ø 6 mm

10015511

At Ø 6 mm the HOLZMANN 10015511 has the smallest cutting radius of the three HOLZMANN round tips - half the diameter of the Ø 12 mm 10015506 and well under the Ø 16 mm 10015509. That is what lets the 10015511, at 0.03 kg net, follow tight coves, narrow beads and small box interiors.

ფასი მოთხოვნით

The price of the 10015511 turns on order quantity, on the small Ø 6 mm size against the larger round geometries, on HOLZMANN's current list price and the exchange rate, on freight consolidation, and on the customs and tax treatment at landing.

ფასის მოთხოვნა

What the HOLZMANN 10015511 carbide round tip is

The HOLZMANN 10015511 is a carbide round turning tip of 6 mm diameter, sold as a single replacement cutter for carbide-insert wood turning tools. The 10015511 is the smallest round tip in the HOLZMANN turning accessory range and is fitted to the bar of an existing carbide tool, so a blunt edge is exchanged in minutes instead of being ground back.

Where a 6 mm round cutter is used

The small radius is the whole point of the 10015511. A 6 mm round edge enters tight coves, narrow beads, small hollow forms and the inside of boxes and lidded vessels where a 12 or 16 mm cutter simply cannot reach. Furniture turners producing chair spindles, finials and decorative mouldings use the 10015511 for the fine profile work that follows the roughing pass.

Choosing between the HOLZMANN round tips

HOLZMANN supplies three round carbide tips: the 6 mm 10015511, the titanium-plated 12 mm 10015506 and the Ti-coated 16 mm 10015509. Cutting load rises with diameter, so the 10015511 is the detail tip rather than the roughing tip, and stock removal is deliberately modest. For flat shoulders and straight sections the square tips 10015508 and 10015510 apply, and the diamond tip 10015507 is the one for sharp corners and V-cuts.

Delivery

The 10015511 is delivered as one carbide tip, 0.03 kg net and 0.04 kg gross, without handle, bar or fixing screw. HOLZMANN does not state a titanium coating for this tip, unlike the 12 mm and 16 mm round cutters. Confirm the pocket and screw of the turning tool in the workshop before ordering.

ძირითადი მახასიათებლები

  • Ø 6 mm round carbide edge - the smallest cutting radius in the range, half the Ø 12 mm 10015506
  • The small radius enters tight coves, narrow beads and the interiors of small boxes and hollow forms
  • 0.03 kg net and 0.04 kg gross - the lightest cut of the three HOLZMANN round geometries
  • Least aggressive round tip in the range, which makes it forgiving on light bars and small lathes
  • HOLZMANN publishes no packaging dimensions for the 10015511 - all three fields read 0 in the data sheet
  • The detail end of the HOLZMANN round range, with the 10015506 and the 10015509 above it

ტექნიკური მახასიათებლები

Cutter shape
Round
Cutter diameter
Ø 6 mm
Material
Carbide
Net weight
0.03 kg
Gross weight
0.04 kg
HOLZMANN article number
10015511

უპირატესობები

  • Ø 6 mm radius reaches detail no larger round cutter can follow
  • Carbide edge is exchanged with a screwdriver instead of being reground
  • Lightest and least aggressive round tip in the HOLZMANN range - forgiving on small lathes

გასათვალისწინებელი

  • No titanium coating specified, unlike the Ø 12 mm and Ø 16 mm round tips
  • Too small for roughing: heavy stock removal needs the 10015509 or a square tip
  • Cutting tip only - no handle, tool bar or fixing screw included, and fit is not universal

ხშირად დასმული კითხვები

Does the HOLZMANN 10015511 carbide tip need 230 V or 400 V?
Neither. The HOLZMANN 10015511 is a carbide cutting tip with no motor and no electrical connection at all. The 10015511 performs identically on a 230 V single-phase lathe and on a 400 V three-phase lathe, because only the lathe draws power.
What does the HOLZMANN 10015511 not do?
The HOLZMANN 10015511 is a small detail cutter, not a roughing tool. The 10015511 will not take heavy passes off a large bowl blank, will not cut flat shoulders or sharp corners, and does not include a handle, tool bar or fixing screw - it is the cutting tip only.
Why choose the 6 mm tip over the 12 mm or 16 mm HOLZMANN round cutters?
The HOLZMANN 10015511 is chosen for reach and fineness. Its Ø 6 mm radius enters small hollows, narrow coves and box interiors that the Ø 12 mm 10015506 and Ø 16 mm 10015509 cannot follow. For stock removal on larger work, those bigger tips are the better buy.
Is the HOLZMANN 10015511 titanium coated?
HOLZMANN's catalogue line for the 10015511 describes it as a carbide round tip of 6 mm diameter and carries no coating designation, so we state nothing about the finish of the 10015511 in either direction - an omitted specification line is not evidence that a coating is absent. Where the surface treatment matters for the timber being turned, ask us to confirm the finish of the 10015511 with HOLZMANN before the order is placed.
Will the HOLZMANN 10015511 fit an existing carbide turning tool?
Only if the seat matches. The HOLZMANN 10015511 sits in a specific pocket and is held by a specific screw, and these vary between tool makes. Check the pocket shape and screw size on the tool in the workshop, or ask the dealer, before ordering the 10015511.
What determines the price of the HOLZMANN 10015511 round tip?
The price of the HOLZMANN 10015511 Ø 6 mm carbide round tip depends on the quantity ordered, on the small size relative to the Ø 12 mm 10015506 and Ø 16 mm 10015509, on HOLZMANN's current list price and the exchange rate on the order date, on whether the tips consolidate with a larger consignment, and on the customs and tax treatment at landing. Because detail tips are consumed faster on fine work, tell us a realistic quantity and we will price the 10015511 against it.
What is the lead time on the HOLZMANN 10015511?
The HOLZMANN 10015511 is ordered in against its HOLZMANN article number and the current lead time is confirmed at quotation. No delivery window is published for the 10015511 in advance, since it follows HOLZMANN's order book and the way the shipment is combined. Ask for the current position when you request pricing.
Is any installation or commissioning charged for the HOLZMANN 10015511?
No. The HOLZMANN 10015511 is a replacement carbide tip fitted with a screwdriver into the pocket of an existing turning tool, so there is nothing to site, level, wire or connect to extraction and no commissioning cost. The only check before ordering the 10015511 is that the tool's pocket accepts a Ø 6 mm insert.
What tooling should be budgeted with the HOLZMANN 10015511?
With the HOLZMANN 10015511 budget for the round-pocket bar and handle it seats in, spare retaining screws, and the tips that do the work a Ø 6 mm radius cannot: the Ø 12 mm 10015506 and Ø 16 mm 10015509 for general curves and roughing, the square 10015510 or 10015508 for cylinders and shoulders. Detail tips wear faster than roughing tips, so treat the 10015511 as a recurring consumable line.
