MZK Manuel Kapi Ebatlama Manual Door Sizing Machine

MZK MANUEL KAPI EBATLAMA — MZK Manuel Kapi Ebatlama Manual Door Sizing Machine

Where the lock machines prepare hardware, the MZK Manuel Kapi Ebatlama sizes the leaf itself: a hand-set saw with a 45 to 90 degree tilting head, linear guideways, a digital dimension display and simultaneous lamp groove cutting. Motor, power and footprint data for the MZK Manuel Kapi Ebatlama is unpublished.

ჭრის სიგანე
265 mm
ჭრის სიგრძე
250 mm
  • ახალი
  • შეკვეთით
ფასი ფასი მოთხოვნით

Price of the MZK Manuel Kapi Ebatlama is driven by current availability from Mizrak, the blade and lamp groove tooling supplied with it, any support tables or extraction added, and delivery and installation in Georgia.

ფასის მოთხოვნა
+995 599 88 74 04
ირაკლი გაყიდვების მენეჯერი
  • კონფიგურაცია თქვენს ძაბვასა და ზომებზე
  • მიწოდება, მონტაჟი და გაშვება ადგილზე
  • ქარხნული გარანტია და სათადარიგო ნაწილები

What the MZK Manuel Kapi Ebatlama does

The MZK Manuel Kapi Ebatlama sizes door leaves under operator control, with the cutting group riding on linear guideways and the dimension read from a digital display rather than a tape measure. The head tilts through a 45° to 90° cradle motion, so bevelled edges and square cuts come from the same setup. The MZK Manuel Kapi Ebatlama can also cut the lamp (glazing) groove at the same time as sizing, which saves returning the leaf for a second pass on shops that produce glazed interior doors.

Who the MZK Manuel Kapi Ebatlama suits

The MZK Manuel Kapi Ebatlama is the entry point into Mizrak’s door sizing range and suits joineries and small door workshops whose volume does not justify an automated line. Where a workshop currently squares doors on a panel saw with a straightedge, the MZK Manuel Kapi Ebatlama brings repeatable dimensions and a proper tilting head without the floor area, power draw or programming demands of the NC and CNC Ripper machines. Manufacturers running continuous batch production will outgrow this machine quickly.

How it compares with the Ripper models

The MZK Manuel Kapi Ebatlama is manual where the MZK NC Ripper KS is numerically controlled and the MZK NC Ripper Double PLC Control is fully automated with a lock group. The manual model carries no PLC, no touchscreen and no lock or hinge routing, so hardware preparation stays a separate operation on a lock machine such as the MZK Kapi Kilit Plus. In exchange, the MZK Manuel Kapi Ebatlama is far simpler to operate, service and install.

Specifications to confirm before ordering

Mizrak’s record for the MZK Manuel Kapi Ebatlama lists general features but no technical table, so no motor power, voltage, air requirement, footprint or weight is stated on this page and nothing has been estimated. The supplier’s own general information cites cutting figures of 265 for width and 250 for length without a consistent unit shown in the Turkish original; these are reproduced exactly as published and should be confirmed in writing, together with the electrical rating and installed dimensions, before an order is placed.

ძირითადი მახასიათებლები

  • 45° to 90° tilting (cradle) head for square and bevelled cuts from one setup
  • Cutting group travels on linear guideways rather than a fixed slide
  • Digital display for dimension setting instead of manual measurement
  • Lamp (glazing) groove and sizing cut can be performed simultaneously
  • Supplier-stated cutting figures of 265 for width and 250 for length, published without a consistent unit
  • Manual operation with no PLC or programming, so operator training is short

ტექნიკური მახასიათებლები

Width Cutting (as published by supplier)
265 mm
Length Cutting (as published by supplier)
250 mm
Tilting (Swivel) Motion
45°–90°
Guideways
Movement on linear guideways
Display
Digital display
Combined Operation
Simultaneous lamp slotting and sizing

უპირატესობები

  • Tilting 45° to 90° head with linear guideways gives repeatable cuts at entry-level cost
  • Lamp groove and sizing in one operation removes a second handling of the leaf
  • Manual operation means short operator training and simple servicing

გასათვალისწინებელი

  • No published technical table: power, footprint, weight and true capacity all need confirming
  • No lock, handle or hinge routing, so a separate hardware machine is still required
  • Manual setting limits throughput and will be outgrown by continuous batch production

ხშირად დასმული კითხვები

Is the MZK Manuel Kapi Ebatlama automatic or manual?
The MZK Manuel Kapi Ebatlama is a manually operated machine with a digital display for setting dimensions; it has no PLC, touchscreen or programmable control. Operators set the MZK Manuel Kapi Ebatlama by hand and read the position from the digital display.
What cutting capacity does the MZK Manuel Kapi Ebatlama have?
Mizrak publishes cutting figures of 265 for width and 250 for length for the MZK Manuel Kapi Ebatlama, but the source data does not print a consistent unit alongside them. Ask the dealer for the maximum door length, width and thickness of the MZK Manuel Kapi Ebatlama in writing before ordering.
What power supply does the MZK Manuel Kapi Ebatlama require?
No voltage, motor power or total power rating is published by Mizrak for the MZK Manuel Kapi Ebatlama. Industrial sizing saws in this range are normally three-phase, but the exact electrical requirement of the MZK Manuel Kapi Ebatlama must be confirmed by the supplier before the workshop connection is prepared.
Does the MZK Manuel Kapi Ebatlama cut lock and hinge seats?
No, the MZK Manuel Kapi Ebatlama sizes door leaves and cuts the lamp groove only; it does not rout lock, handle or hinge seats. Hardware preparation after the MZK Manuel Kapi Ebatlama needs a separate lock machine such as the MZK Kapi Kilit Plus.
What does the tilting head on the MZK Manuel Kapi Ebatlama do?
The head of the MZK Manuel Kapi Ebatlama tilts through a 45° to 90° cradle motion, allowing bevelled and square edges to be cut without changing setup. That tilting range is one of the few figures Mizrak publishes for the MZK Manuel Kapi Ebatlama.
How is the MZK Manuel Kapi Ebatlama delivered and installed in Georgia?
Delivery, positioning, commissioning and operator training for the MZK Manuel Kapi Ebatlama are quoted per order through the Georgian dealer. Because the supplier lists the MZK Manuel Kapi Ebatlama as an inactive model, confirm current availability and lead time before committing.
How much does the MZK Manuel Kapi Ebatlama cost?
The MZK Manuel Kapi Ebatlama is supplied on quotation rather than at a list price. What moves the figure for the MZK Manuel Kapi Ebatlama is current availability from Mizrak, the blade and lamp groove tooling included, any support tables or extraction added, and delivery and installation in Georgia. As the entry point into the door sizing range it should be quoted against the NC Ripper models for comparison.
Is the MZK Manuel Kapi Ebatlama still available, and what is the lead time?
Mizrak lists the MZK Manuel Kapi Ebatlama as an inactive model, so current availability has to be confirmed before anything else. If the MZK Manuel Kapi Ebatlama is still built, it is made to order and the lead time is confirmed at quotation; if it is not, ask for the current equivalent in the Mizrak door sizing range to be quoted instead.
What is needed to install and commission the MZK Manuel Kapi Ebatlama?
The MZK Manuel Kapi Ebatlama needs a level floor with clear infeed and outfeed room for a full door leaf on both sides, a three-phase connection at the rating the supplier confirms, and extraction at the blade. Delivery, positioning and commissioning of the MZK Manuel Kapi Ebatlama are quoted as separate items, not included in the machine price.
What tooling and consumables should be budgeted with the MZK Manuel Kapi Ebatlama?
Budget for the saw blade and its resharpening, the cutter for the lamp groove, and the extraction connection, none of which is listed as part of the MZK Manuel Kapi Ebatlama. Because the MZK Manuel Kapi Ebatlama cuts no lock, handle or hinge seats, a separate lock machine such as the MZK Kapi Kilit Plus also has to be budgeted if hardware is prepared in the workshop.
