MZK NC RIPPER KS — MZK NC Ripper KS Door Sizing Machine 1 / 4

MIZRAK

MZK NC Ripper KS Door Sizing Machine

MZK NC RIPPER KS

The MZK NC Ripper KS works the narrow side of door production: components 10 to 270 mm wide and up to 2500 mm long rather than full leaves, cut by nine saw blades with an integrated sanding unit, lamp groove and 5 mm architrave recessing. 25.75 kW, 4000 x 1700 x 1700 mm, 1450 kg.

ფასი მოთხოვნით

The price of the MZK NC Ripper KS is driven by the blade set specified for the component widths you run, whether extraction and a compressor are quoted with it, and delivery, rigging and commissioning at the Georgian site.

ფასის მოთხოვნა

What the MZK NC Ripper KS does

The MZK NC Ripper KS sizes door leaves and door components and finishes the cut edge in the same pass. Nine saw blades work the piece, a 0.37 kW sanding motor at 3000 rpm cleans the sawn edge, and the machine also opens the lamp (glazing) groove and drops a 5 mm architrave recess. Maximum workpiece length on the MZK NC Ripper KS is 2500 mm and the processing width range is 10 to 270 mm, so the machine handles both full leaves and the narrower frame and casing components that accompany them.

Motors and cutting group

The MZK NC Ripper KS uses a 4 kW longitudinal cutting motor at 3445 rpm and a 5.5 kW cross-cutting motor at 3000 rpm, with a 0.37 kW X-axis motor positioning the cut. Both the longitudinal and cross-cut saws are Ø250 x 30 x 3.2 mm. Total power consumption for the MZK NC Ripper KS is 25.75 kW on a 380-400 V AC, 50-60 Hz supply, with compressed air at 6-8 bar. Measured sound level is LWA 111.1 dB(A), which means hearing protection is mandatory at the operator station.

Who the MZK NC Ripper KS suits

The MZK NC Ripper KS suits door manufacturers who need automated sizing with an edge finish but do not need integrated lock and hinge routing. At 4000 x 1700 x 1700 mm and 1450 kg, the MZK NC Ripper KS occupies roughly a third less floor than the twin-bridge Ripper models and draws 25.75 kW instead of 30-38 kW, which puts it within reach of workshops that cannot support a full line.

How it differs from the twin-bridge models

The MZK NC Ripper KS has a single cutting group where the MZK NC Ripper Double PLC Control and MZK CNC Ripper Double have two bridges and a lock group. That means the KS does not cut lock seats, handle pockets or faceplate recesses: hardware preparation stays on a separate machine such as the MZK Kapi Kilit Plus. What the KS adds over the manual sizing saw is numerical control, nine-blade working and the sanding unit.

ძირითადი მახასიათებლები

  • Maximum workpiece length of 2500 mm with a 10 to 270 mm processing width, which suits frame, jamb and architrave components rather than full door leaves
  • Works with nine saw blades in a single cutting group
  • 0.37 kW sanding motor at 3000 rpm finishes the sawn edge in the same pass
  • 5.5 kW cross-cutting motor at 3000 rpm and 4 kW longitudinal motor at 3445 rpm
  • Ø250 x 30 x 3.2 mm longitudinal and cross-cutting saw blades
  • Lamp (glazing) groove cutting and 5 mm architrave recessing
  • 25.75 kW total power consumption, 4000 x 1700 x 1700 mm footprint, 1450 kg

ტექნიკური მახასიათებლები

Rated Current
380–400V AC, 50–60Hz
Sound Level
LWA: 111.1 dB(A)
Air Pressure
6 – 8 Bar
Maximum Processing Width
10–270 mm
Maximum Workpiece Length
2500 mm
Number of Saw Blades
9
Architrave (Door Jamb) Recessing
5 mm
Longitudinal Cutting Saw
Ø250 x 30 x 3.2 mm
Cross Cutting Saw
Ø250 x 30 x 3.2 mm
Longitudinal Cutting Motor
4 kW, 3445 rpm
Cross Cutting Motor
5.5 kW, 3000 rpm
Start and End Cutting Motors
5.5 kW
Sanding Motor
0.37 kW, 3000 rpm
X-Axis Motor
0.37 kW, 3000 rpm
Total Power Consumption
25.75 kW
Machine Width
1700 mm
Machine Length
4000 mm
Machine Height
1700 mm
Machine Weight
1450 kg

უპირატესობები

  • Sizing and edge sanding completed in one pass, removing a separate finishing step
  • 25.75 kW draw and a 4000 x 1700 mm footprint are far easier to accommodate than the twin-bridge models
  • Handles 10-270 mm wide components as well as full leaves, covering frames and casings

გასათვალისწინებელი

  • No lock, handle or hinge routing, so a separate hardware machine is still required
  • LWA 111.1 dB(A) sound level makes hearing protection and machine siting a real consideration
  • Three-phase 380-400 V only, with a mandatory 6-8 bar compressed air supply and separate extraction

ხშირად დასმული კითხვები

What is the maximum workpiece size for the MZK NC Ripper KS?
The MZK NC Ripper KS handles workpieces up to 2500 mm long with a processing width range of 10 to 270 mm. Pieces longer than 2500 mm or outside that 10-270 mm width range fall beyond the published capacity of the MZK NC Ripper KS.
What power supply does the MZK NC Ripper KS need?
The MZK NC Ripper KS runs on a three-phase 380-400 V AC, 50-60 Hz supply with a total power consumption of 25.75 kW, and additionally requires compressed air at 6-8 bar. The MZK NC Ripper KS cannot be operated from a single-phase supply.
Does the MZK NC Ripper KS cut lock and hinge seats?
No, the MZK NC Ripper KS is a sizing machine with sanding, lamp groove and architrave recessing functions and does not rout lock seats, handle pockets or hinge seats. Hardware preparation after the MZK NC Ripper KS requires a separate lock machine such as the MZK Kapi Kilit Plus.
What saw blades does the MZK NC Ripper KS use?
The MZK NC Ripper KS uses Ø250 x 30 x 3.2 mm blades for both longitudinal and cross cutting and is described as working with nine saw blades. Replacement blades for the MZK NC Ripper KS must match the Ø250 mm diameter, 30 mm bore and 3.2 mm kerf.
How noisy is the MZK NC Ripper KS?
The measured sound level of the MZK NC Ripper KS is LWA 111.1 dB(A). Hearing protection is required at the operator station of the MZK NC Ripper KS, and the machine should be sited with that noise level in mind relative to neighbouring workstations.
How much space does the MZK NC Ripper KS require and how is it installed?
The MZK NC Ripper KS measures 4000 mm long, 1700 mm wide and 1700 mm high and weighs 1450 kg, so a solid floor and clear infeed and outfeed access for 2500 mm workpieces are needed. Delivery, rigging and commissioning of the MZK NC Ripper KS are quoted per order by the Georgian dealer, and availability should be confirmed because the supplier lists the model as inactive.
How much does the MZK NC Ripper KS cost?
The MZK NC Ripper KS is supplied on quotation, not at a list price. The figure for the MZK NC Ripper KS depends on the nine-blade set specified for the component widths you cut, whether extraction and a 6-8 bar compressor are included, and delivery, rigging and commissioning in Georgia. Send your frame and architrave profile drawings for a written quotation.
Is the MZK NC Ripper KS still available and how long is the wait?
Mizrak currently lists the MZK NC Ripper KS as inactive in its catalogue, which normally indicates a built-to-order model rather than a discontinued one. Availability of the MZK NC Ripper KS and the current lead time are confirmed in writing at quotation, together with transport time into Georgia.
What does installing the MZK NC Ripper KS involve?
Installing the MZK NC Ripper KS means siting a 4000 x 1700 x 1700 mm, 1450 kg machine on a solid level floor with straight infeed and outfeed for 2500 mm components, connecting a 380-400 V three-phase supply sized for 25.75 kW, feeding compressed air at 6-8 bar and ducting the hoods to extraction. Because the MZK NC Ripper KS is rated at LWA 111.1 dB(A), plan its position relative to neighbouring workstations.
What consumables should be budgeted with the MZK NC Ripper KS?
Running the MZK NC Ripper KS consumes Ø250 x 30 x 3.2 mm longitudinal and cross-cutting blades across a nine-blade group, plus sanding consumables for the 0.37 kW sanding unit and regular blade sharpening. Budget a spare blade set for the MZK NC Ripper KS and confirm on the quotation which blades ship with the machine.
