LINA 2136 EVO — Mizrak LINA 2136 EVO CNC Nesting Router 1 / 4

MIZRAK

Mizrak LINA 2136 EVO CNC Nesting Router

LINA 2136 EVO

Entry point of the LINA range, the LINA 2136 EVO holds work on 24 automatic vacuum points where the LINA 2136 uses 48, and reaches 70 m/min on Y against 90 m/min. Spindle, tooling and capacity match: 7.5-9 kW HSD, 13 HSK F63 holders, 45 mm maximum Z thickness.

ფასი მოთხოვნით

The price of a LINA 2136 EVO is driven by the entry specification itself - 24 vacuum points and 70 m/min on Y rather than the 48 points and 90 m/min of the LINA 2136 - together with the tooling package for the 13 HSK F63 holders, the software licence term after the included 2D rental, and transport, rigging, commissioning and training.

ფასის მოთხოვნა

What the LINA 2136 EVO does

The LINA 2136 EVO is the lowest-cost way into Mizrak’s LINA nesting range, and its specification is honest about that. A 7.5–9 kW HSD spindle, a 13-position HSK F63 automatic tool changer and 24 vacuum suction points across 6 adjustable zones let the LINA 2136 EVO cut, groove and shape flat cabinet parts up to 45 mm thick. Axis speeds are the trade: 20 m/min on Z and 70 m/min on Y mean the LINA 2136 EVO takes longer per sheet than any other machine in the range.

Who the LINA 2136 EVO suits

Small and medium furniture workshops replacing hand-marked, hand-drilled cabinet work are the buyer for the LINA 2136 EVO. In that setting the comparison is not against a faster CNC but against a saw, a drill and a router table, and the LINA 2136 EVO wins on accuracy and repeatability regardless of its cycle time. Automatic tool measurement and tool assignment on the LINA 2136 EVO matter more here than raw speed, because the operator is usually learning CNC on this machine.

How the LINA 2136 EVO compares in the LINA range

The LINA 2136 EVO is separated from the LINA 2136 and LINA 2136 ED by hold-down and speed: those models carry 48 vacuum suction points against 24 on the EVO, run 30 m/min on Z and 90 m/min on Y, and list an automatic lubrication system that the LINA 2136 EVO does not. Everything else in that comparison is shared — the same 7.5–9 kW HSD spindle, 13 HSK F63 holders, 250 m³ pump, 45 mm thickness, compact flat table and 2D rental software. The 11–13 kW LINA 2136 PLUS X is a class above all three.

What is included with the LINA 2136 EVO

Standard supply of the LINA 2136 EVO covers 13 HSK F63 tool holders, the 250 m³ vacuum pump serving 24 suction points in 6 adjustable zones, the tool cooling system, automatic tool measurement and tool assignment, the compact flat table, a handheld terminal and 2D software on a rental licence. Cutters and holders for the LINA 2136 EVO are quoted separately, extraction is a separate installation, and lubrication arrangements should be confirmed because no automatic system is listed for the LINA 2136 EVO.

ძირითადი მახასიათებლები

  • 24 automatic vacuum suction points across 6 adjustable zones - half the 48 points of the LINA 2136
  • 70 m/min maximum Y-axis speed and 20 m/min maximum Z-axis speed, the slowest axes in the LINA range
  • 7.5-9 kW HSD spindle motor with a tool cooling system
  • 13 HSK F63 tool holders in a fixed automatic tool changer
  • 250 m³ vacuum pump serving the compact flat table
  • 45 mm maximum working thickness on the Z axis, the same as the LINA 2136
  • Automatic tool measurement and tool assignment
  • Handheld terminal and 2D software supplied on rental

ტექნიკური მახასიათებლები

Fixed Tool Change
13 pcs HSK F63
Vacuum Suction Points
24 automatic points in 6 adjustable zones
Vacuum Pump
250 m³
Max. Working Thickness (Z axis)
45 mm
Max. Working Speed (Z axis)
20 m/min
Max. Working Speed (Y axis)
70 m/min
Spindle Motor
7.5–9 kW HSD
Tool Cooling System
Included
Software
2D, rental licence
Working Table
Compact flat table
Tool Measurement
Automatic tool measurement and tool assignment
Hand Terminal
Included

უპირატესობები

  • Lowest entry price into automatic tool change and zoned vacuum in the LINA range
  • Automatic tool measurement and assignment make it forgiving for an operator new to CNC
  • Same 7.5–9 kW HSD spindle, 13 HSK F63 holders and 250 m³ pump as the higher LINA 2136

გასათვალისწინებელი

  • 24 suction points instead of 48 — weaker hold-down when nesting many small parts
  • Slowest axes in the range at 20 m/min on Z and 70 m/min on Y, so cycle times are longer
  • No automatic lubrication system is listed, and the 2D software is a rental licence

ხშირად დასმული კითხვები

How does the LINA 2136 EVO differ from the LINA 2136?
The LINA 2136 EVO has 24 vacuum suction points against 48 on the LINA 2136, and runs slower at 20 m/min on Z and 70 m/min on Y against 30 and 90 m/min. The LINA 2136 EVO also does not list the automatic lubrication system that the LINA 2136 includes; spindle, tool changer, pump and 45 mm thickness are the same on both.
How thick a workpiece can the LINA 2136 EVO machine?
The LINA 2136 EVO has a maximum working thickness of 45 mm on the Z axis, which covers standard 18 mm panel and doubled panel but not thick worktop material.
What working area does the LINA 2136 EVO have?
Mizrak does not publish a working area, footprint or weight for the LINA 2136 EVO in its current datasheet, so the maximum sheet size and the space needed for the LINA 2136 EVO must be confirmed in writing with the supplier.
What power supply does the LINA 2136 EVO need?
The electrical rating of the LINA 2136 EVO is not published by Mizrak, but a 7.5–9 kW HSD spindle and a 250 m³ vacuum pump require a 400 V three-phase supply and compressed air. Confirm the installed power of the LINA 2136 EVO before preparing the workshop connection.
Is the 24-point vacuum table on the LINA 2136 EVO enough for nesting?
The LINA 2136 EVO holds work on 24 automatic suction points across 6 adjustable zones, which is half the point count of the LINA 2136. For nesting many very small parts from one sheet, the denser 48-point table of the LINA 2136 or LINA 2136 ED gives more reliable hold-down than the LINA 2136 EVO.
Does the LINA 2136 EVO have automatic lubrication?
Mizrak does not list an automatic lubrication system for the LINA 2136 EVO, although it lists one on the LINA 2136 and LINA 2136 ED. The lubrication arrangement of the LINA 2136 EVO and its maintenance intervals should be confirmed with the supplier before purchase.
How much does the LINA 2136 EVO cost?
The LINA 2136 EVO is supplied on quotation rather than at a published price, and it is the entry point of the LINA range, so it is quoted below the LINA 2136 on account of its 24-point vacuum table and 70 m/min Y axis. The figure then moves with the cutter and holder package for the 13 HSK F63 positions, the software licence term after the included 2D rental, the extraction plant, and transport, commissioning and training. Ask for the LINA 2136 EVO and LINA 2136 to be quoted side by side.
How quickly can a LINA 2136 EVO be delivered?
The LINA 2136 EVO is built to order by Mizrak, so the current lead time is confirmed at quotation rather than offered from stock. Request the LINA 2136 EVO delivery window alongside the price and use the interval to prepare three-phase power, compressed air and dust extraction ducting.
What does installing a LINA 2136 EVO involve?
Installing a LINA 2136 EVO covers siting and levelling the machine on an industrial floor with room to hand-load sheets, positioning the 250 m³ vacuum pump, three-phase connection by a qualified electrician, compressed air connection, and ducting to a dust extraction plant. Because Mizrak publishes no weight or footprint for the LINA 2136 EVO, ask for those figures with the quotation before arranging offloading.
What should be budgeted on top of the LINA 2136 EVO price?
Budget alongside the LINA 2136 EVO for HSK F63 holders and router cutters for the 13-place changer, spoilboard material, vacuum pump service items, a dust extraction plant with ducting, and renewal of the 2D rental software when the included term ends. Because the LINA 2136 EVO has 24 vacuum points rather than 48, also allow for good-quality spoilboard and clamping aids for small parts.
