NETMAK FRS 1250 Vertical Spindle Router (Sakuli Freze)

FRS 1250 Sakuli Freze Makinasi — NETMAK FRS 1250 Vertical Spindle Router (Sakuli Freze)

With 1250 mm between cutter and column, the NETMAK FRS 1250 reaches into a full door leaf where the FRS 900 stops at 910 mm, and carries a larger 960 x 1220 mm table at 850 kg. Spindle and travels match the FRS 900: 9000-18000 rpm, a 12-14 mm collet, 200 mm table and 80 mm spindle stroke.

ძრავის სიმძლავრე
2.98 kW
მაგიდის ზომა
960 x 1220 mm
შპინდელი
80 mm
ცანგა
12-14 mm
  • ახალი
  • შეკვეთით
ფასი ფასი მოთხოვნით

FRS 1250 pricing is driven by the 1250 mm reach specification rather than the FRS 900's 910 mm, the cutter, collet and template package quoted with the machine, air preparation equipment, and delivery and installation of an 850 kg, 2100 mm wide machine.

ფასის მოთხოვნა
+995 599 88 74 04
ირაკლი გაყიდვების მენეჯერი
  • კონფიგურაცია თქვენს ძაბვასა და ზომებზე
  • მიწოდება, მონტაჟი და გაშვება ადგილზე
  • ქარხნული გარანტია და სათადარიგო ნაწილები

What the FRS 1250 does

The NETMAK FRS 1250 routs, recesses and profiles from above the workpiece on large components, with 1250 mm of clearance between the cutter and the column. That reach is the reason to buy this model: a full door leaf can be positioned so the cutter works well inside the panel rather than only near its edge. The head is raised and lowered pneumatically, the spindle turns at 9000 to 18000 rpm on a 3.2-4 HP motor, and cutters are held in a 12-14 mm collet.

Who the FRS 1250 suits

The FRS 1250 is aimed at door manufacturers and large-panel joinery shops. Lock and latch pockets, hinge recesses, letterbox and vision-panel apertures, and decorative face routing on door leaves all sit within its working envelope. The table measures 960 x 1220 mm and travels 200 mm, the spindle adds 80 mm of its own travel, and the maximum spindle-to-table gap is 260 mm, which leaves usable room for template fixtures above a thick door blank. Five preset height steps make a sequence of different depths repeatable, and the 850 kg monoblock steel frame keeps deflection out of a long reach.

FRS 1250 against the FRS 900

The FRS 1250 and the FRS 900 share every cutting specification: 9000-18000 rpm spindle, 3.2-4 HP motor, 12-14 mm collet, 200 mm table travel, 80 mm spindle travel, five height steps and 260 mm maximum spindle-to-table clearance. The FRS 1250 differs in scale, with 1250 mm of column clearance instead of 910 mm, a 960 x 1220 mm table instead of 790 x 970 mm, 850 kg instead of 630 kg and a 2100 x 1200 x 1650 mm footprint instead of 1700 x 1000 x 1650 mm. The FRS 1250 costs 400 mm of workshop length; in return it removes the size limit that sends door work to a subcontractor.

What is included with the FRS 1250

Standard equipment on the FRS 1250 includes the monoblock steel body, pneumatic head raise and lower, stepped depth adjustment on the spindle, a 24 volt lighting system and the blade and hand guard. Router cutters, templates, hold-down clamps, the compressed air installation and chip extraction are not supplied with the FRS 1250 and must be specified according to the door or panel programme being run.

ძირითადი მახასიათებლები

  • 1250 mm clearance between cutter and column, 340 mm more reach than the FRS 900, for full door leaves
  • 960 x 1220 mm work table with 200 mm of table travel
  • Spindle speed range of 9000 to 18000 rpm, unchanged from the FRS 900
  • 3.2-4 HP motor driving a 12-14 mm collet
  • Pneumatic head raise and lower with 80 mm of spindle travel
  • Five preset height steps and 260 mm maximum spindle-to-table clearance
  • 24 volt work lighting plus blade and hand guard as standard
  • 850 kg monoblock steel body, 2100 x 1200 x 1650 mm overall

ტექნიკური მახასიათებლები

Product code
FRS 1250
Table size
960 x 1220 mm
Table travel
200 mm
Cutter to column clearance
1250 mm
Spindle travel
80 mm
Preset height steps
5
Max. spindle to table clearance
260 mm
Spindle speed
9000-18000 rpm
Motor power
3.2-4 HP
Collet
12-14 mm
Overall dimensions
2100 x 1200 x 1650 mm
Net weight
850 kg
Standard equipment
Monoblock steel body, pneumatic raise and lower, stepped depth adjustment on the spindle, 24 volt lighting system, blade and hand guard

უპირატესობები

  • 1250 mm column clearance keeps full door leaves in-house
  • 850 kg frame resists deflection at the extremes of its reach
  • Pneumatic plunge with five preset depths makes batch work repeatable

გასათვალისწინებელი

  • Needs 2100 x 1200 mm of floor plus panel handling room around it
  • Compressed air supply, cutters and templates are all separate purchases
  • Manual template-guided operation, so complex profiles still need a CNC router

ხშირად დასმული კითხვები

Can the NETMAK FRS 1250 rout a full door leaf?
The FRS 1250 offers 1250 mm between the cutter and the column, so the FRS 1250 can reach 1250 mm in from the edge of a panel, which covers centre positions on most standard door leaves. The 960 x 1220 mm table supports the panel while the pneumatic head plunges.
How does the FRS 1250 differ from the FRS 900?
The FRS 1250 has 1250 mm of column clearance against 910 mm on the FRS 900, a 960 x 1220 mm table against 790 x 970 mm, and weighs 850 kg against 630 kg. Spindle speed, motor power, collet size, table travel, spindle travel and depth steps are identical on the FRS 1250 and the FRS 900.
What does the FRS 1250 need to run?
The FRS 1250 needs an electrical supply, a compressed air connection for the pneumatic head and a chip extraction take-off, none of which is included with the machine. Router cutters with shanks matching the 12-14 mm collet and job-specific templates must also be bought for the FRS 1250 separately.
How thick a door blank fits under the FRS 1250 head?
The FRS 1250 allows up to 260 mm between spindle and table, and the operator should deduct the thickness of any template or fixture from that figure. Spindle travel on the FRS 1250 is 80 mm and table travel is 200 mm, which together set the plunge range available in one setup.
Is the FRS 1250 programmable?
No, the FRS 1250 is a manual overhead router that follows templates and mechanical stops, and the FRS 1250 has no CNC control, no tool changer and no programmed axes. Shops wanting programmed door machining should compare the FRS 1250 with the NETMAK CNC 2411 CNC router.
How much floor space does the FRS 1250 need?
The FRS 1250 measures 2100 x 1200 x 1650 mm and weighs 850 kg, and needs additional clear space around the table for manoeuvring full-size door leaves. Plan the delivery route for the FRS 1250 with a forklift or pallet truck in mind.
How much does the NETMAK FRS 1250 cost?
The NETMAK FRS 1250 overhead router is quoted rather than sold at a listed price. The FRS 1250 quotation is shaped by the reach specified - 1250 mm on the FRS 1250 against 910 mm on the FRS 900 - the cutter and template package supplied with the machine, compressed air preparation for the pneumatic head, and delivery and installation of an 850 kg machine in Georgia. If your largest workpiece fits within 910 mm of reach, ask for the FRS 900 to be quoted alongside the FRS 1250.
Is the NETMAK FRS 1250 available quickly?
The NETMAK FRS 1250 is built to order, so the FRS 1250 lead time is confirmed at quotation rather than published. Because the FRS 1250 and FRS 900 share their spindle, motor, collet and travels and differ mainly in reach and table size, availability of both is worth checking together when reach is not the deciding factor. Ask for current FRS 1250 availability with your enquiry.
What is needed to install and commission an FRS 1250?
An FRS 1250 installation needs a level floor for 850 kg on a 2100 x 1200 mm footprint plus working space around the 960 x 1220 mm table for handling door leaves, machine levelling, a three-phase electrical connection by a qualified electrician, a clean dry compressed air supply for the pneumatic head raise and lower, and chip extraction connected to the guard. NETMAK does not publish the FRS 1250's supply voltage, phase or air pressure requirement, so these are confirmed at quotation; delivery, offloading and commissioning can be included in the quotation.
What tooling and consumables should be budgeted with an FRS 1250?
The FRS 1250 is quoted as a bare machine, so budget separately for router cutters matched to the 12-14 mm collet and the 9000-18000 rpm range, templates and hold-downs sized for door leaves, an air preparation set for the pneumatic head, and a chip extractor. On an FRS 1250 the template and cutter set is often the difference between a machine that earns immediately and one that waits, so it belongs in the same quotation.
