HOLZMANN ABS4000 Dust Collector – 3900 m³/h, Height Adjustable

ABS4000 — HOLZMANN ABS4000 Dust Collector – 3900 m³/h, Height Adjustable

The ABS4000 is the collector for a low workshop: its body is height adjustable to a maximum of 1950 mm, some 250 mm under the fixed 2200 mm column of the ABS3000SE. A 2200 W motor at 2800 min-1 still delivers 3900 m³/h at 2100 Pa through ports of 1 x 150 mm and 3 x 100 mm, at 47.98 kg net on four casters.

ძრავის სიმძლავრე
2.2 kW
ძაბვა
230V
წონა
47.98 kg
  • ახალი
  • შეკვეთით
ფასი ფასი მოთხოვნით

The ABS4000 price is driven by the 230V or 400V variant, whether a distributor piece is added, hose and blast gates for the 150 mm and 100 mm ports, spare bags, delivery, and duty and VAT.

ფასის მოთხოვნა
+995 599 88 74 04
ირაკლი გაყიდვების მენეჯერი
  • კონფიგურაცია თქვენს ძაბვასა და ზომებზე
  • მიწოდება, მონტაჟი და გაშვება ადგილზე
  • ქარხნული გარანტია და სათადარიგო ნაწილები

What the HOLZMANN ABS4000 does

The HOLZMANN ABS4000 is the high-airflow single-bag collector of the HOLZMANN range, pairing a 2200 W motor at 2800 min-1 with a 305 mm fan wheel to move 3900 m³/h at 2100 Pa. Three machines can be connected simultaneously through the distributor, using the 1 x 150 mm main and 3 x 100 mm branch ports, and the collected chips fall into a bag of ø503 x 1000 mm. The distinguishing feature of the ABS4000 is that its body is height adjustable, with a maximum height of 1950 mm.

Who the ABS4000 suits

The ABS4000 suits joineries and furniture workshops with low ceilings or a mezzanine, where a fixed 2.2 metre collector will not stand upright. Being able to lower the ABS4000 while keeping 3900 m³/h is a real advantage in the older industrial spaces many Georgian workshops occupy. At 47.98 kg net on four casters, the ABS4000 is still a one-person machine to move between a planer, a saw and a moulder.

How the ABS4000 differs from the ABS3000SE and ABS5000SE

Placed against the ABS3000SE, the ABS4000 is the more powerful single-bag option: 2200 W instead of 1500 W and 3900 instead of 3000 m³/h, with a height-adjustable body the ABS3000SE does not have. Against the ABS5000SE the position reverses — the ABS5000SE has the same 2200 W motor but splits the air across two filters and two bags for 5000 m³/h and four branch ports, and is sold only in 400V. The ABS4000 exists in both ABS4000_230V and ABS4000_400V, so a shop without three-phase power can still reach nearly 4000 m³/h.

Practical points before ordering the ABS4000

The ABS4000 ships with the distributor piece needed for multiple machines, and its large filter surface is what allows the high airflow figure to be held in use. Hoses, clamps and blast gates are specified separately according to the machines being connected, and the Ø150 mm main port should be used for the machine producing the greatest chip volume.

ძირითადი მახასიათებლები

  • Height-adjustable body, maximum 1950 mm, for workshops with beams, a mezzanine or a low ceiling
  • 3900 m³/h at 2100 Pa from a 2200 W motor turning at 2800 min-1
  • Ports of 1 x 150 mm and 3 x 100 mm, ready to take a distributor piece
  • 305 mm fan wheel
  • Chip bag ø503 mm diameter x 1000 mm long
  • 47.98 kg net, 52.56 kg gross, on four casters
  • Offered as 230V (EAN 9120039909332) and 400V (EAN 9120039909325)

ტექნიკური მახასიათებლები

Motor power S1
2200 W
Speed
2800 min-1
Voltage
230V (230V variant); 400V variant also offered
Dust collector port
1 x 150 mm / 3 x 100 mm
Max. height
1950 mm
Suction performance
3900 m³/h
Chip bag diameter
503 mm
Chip bag length
1000 mm
Fan wheel diameter
305 mm
Hypotension (static pressure)
2100 Pa
Net weight
47.98 kg
Gross weight
52.56 kg
EAN code (230V variant)
9120039909332

უპირატესობები

  • 3900 m³/h at 2100 Pa from a 48 kg mobile unit
  • Height adjustable to 1950 mm for low-ceiling workshops
  • Both 230V and 400V variants available

გასათვალისწინებელი

  • Bag separation only — no cyclone or automatic filter cleaning
  • No published noise figure in the manufacturer data
  • Hoses, clamps and blast gates are not included

ხშირად დასმული კითხვები

Is the HOLZMANN ABS4000 available in 230V and 400V?
Yes. The HOLZMANN ABS4000 comes as ABS4000_230V for a single-phase 230V socket and ABS4000_400V for a three-phase 400V supply, both with the 2200 W motor. The 230V variant of the ABS4000 is the one to choose for a workshop with no three-phase connection.
What does the HOLZMANN ABS4000 not do?
The HOLZMANN ABS4000 has no cyclone separator, no filter cartridge and no automatic filter cleaning — those belong to the RLE1500. The ABS4000 is also not a floor or liquid vacuum, its bag is emptied by hand, and hoses and blast gates are not part of the delivery.
Why is the ABS4000 height adjustable?
The HOLZMANN ABS4000 has a height-adjustable body with a maximum height of 1950 mm so it can be lowered to fit under low workshop ceilings, beams or a mezzanine while still delivering its 3900 m³/h.
How does the ABS4000 compare with the ABS3000SE?
The HOLZMANN ABS4000 uses a 2200 W motor for 3900 m³/h at 2100 Pa, against the ABS3000SE's 1500 W and 3000 m³/h at 2200 Pa. The ABS4000 adds height adjustment; both are single-bag machines offered in 230V and 400V, so the ABS4000 is the choice when more airflow or a lower overall height is needed.
How many machines can the ABS4000 serve?
The HOLZMANN ABS4000 has 1 x 150 mm and 3 x 100 mm ports and takes a distributor piece, so several woodworking machines can be connected to the ABS4000 at the same time.
How large is the chip bag on the ABS4000?
The HOLZMANN ABS4000 collects into a chip bag of ø503 mm diameter and 1000 mm length, which is emptied by hand when full.
What drives the quoted price of a HOLZMANN ABS4000?
The price of a HOLZMANN ABS4000 is driven by the variant ordered (230V or 400V), whether a distributor piece is added to use the 3 x 100 mm ports, the hose, clamps and blast gates specified for the 1 x 150 mm trunk and its branches, spare chip bags, and delivery with duty and VAT into Georgia. Tell us your ceiling height and machine layout and the ABS4000 quotation will reflect the actual connection work.
How quickly can a HOLZMANN ABS4000 be supplied?
The HOLZMANN ABS4000 is built to order and the current lead time is confirmed at quotation. The variant chosen and whether a distributor and hose ship with the ABS4000 both bear on the confirmed date.
Does the ABS4000 need installation work?
Installation of a HOLZMANN ABS4000 is limited to standing it level, setting the height-adjustable body to the headroom available up to 1950 mm, connecting a supply that matches the variant, and running hose from the 150 mm and 100 mm ports. No foundation or fixed ducting is required, though a workshop serving three machines will want blast gates.
What should be budgeted separately with an ABS4000?
Budget separately from the HOLZMANN ABS4000 for the distributor piece if you intend to run several machines, 150 mm and 100 mm hose with clamps, blast gates, and replacement ø503 x 1000 mm chip bags. These are quoted as individual lines against the ABS4000 so the installed cost is clear.
