HOLZMANN
HOLZMANN VST3000 Panel Glueing Press (4 x 2.5 t)
VST3000
Each of the four pressing units on the HOLZMANN VST3000 is rated 2.5 t, the higher force per unit of the two VST presses, and it is applied mechanically: no hydraulic pack, no valves, no power connection anywhere in the data. The 220 kg frame clamps to 1550 mm, its units moving on a 50 bore pitch down to 240 mm apart.
The quoted price for the VST3000 is driven above all by the XL freight of a 260 kg item packed 3030 mm long and its customs clearance into Georgia, together with the number of presses ordered and whether unloading and positioning on site are included.
ფასის მოთხოვნაWhat the HOLZMANN VST3000 does
The HOLZMANN VST3000 clamps glued boards edge to edge into flat, square panels: table tops, door blanks, stair treads and worktops. Four pressing units, each rated 2.5 t, apply the clamping force, and a self-holding function keeps that pressure constant while the glue cures instead of bleeding off as the timber compresses. The cylinder guide is operated by a side-positioned spring and solid nuts hold the setting, so the operator sets the press and moves on to the next job.
Who the VST3000 suits
The VST3000 is the right press for a joinery or furniture workshop gluing panels along the full length of the frame, with total dimensions given as 2040/3000 mm. The pressing units slide along the frame and are height-adjustable, with a bore pitch of 50, a minimum unit spacing of 240 mm and a maximum clamp height of 1550 mm, so the VST3000 handles both a narrow run of staves and a tall stack of panels clamped at once. The steel construction weighs 220 kg net, which is what keeps the frame from flexing under load.
VST3000 compared with the HOLZMANN VSTR3000
The two presses share the frame dimensions, the 50 bore pitch, the 240 mm minimum unit spacing and the 1550 mm clamp height. The VST3000 carries four vertical pressing units of 2.5 t. The VSTR3000 carries six units, four vertical and two horizontal, of 2 t each, centrally controlled, with hydraulic cylinders and valves and extra bracing against frame twist, at 325 kg net. Choose the VST3000 for straightforward panel gluing at lower weight and cost; choose the VSTR3000 when horizontal pressure is needed to hold panels flat.
Delivery
The VST3000 ships as an XL item at 260 kg gross in a package 3030 mm long.
ძირითადი მახასიათებლები
- Four pressing units at 2.5 t each - the higher force per individual unit of the two VST presses
- Purely mechanical clamping: no hydraulic cylinders, no valves, nothing to bleed, top up or leak onto a glued panel
- Cylinder guide operated by a side-positioned spring, with solid nuts locking each setting in place
- Self-holding function keeps the pressure on the glue line as the timber compresses, without a return to re-tighten
- 220 kg net / 260 kg gross - 105 kg lighter than the VSTR3000 and easier to move within a workshop
- Maximum clamp height 1550 mm, with pressing units repositioned on a 50 bore pitch down to a 240 mm minimum spacing
- No motor, no voltage and no air pressure appear anywhere in the VST3000 technical data: the press needs floor space, not services
- Ships as an XL freight item, packed 3030 x 360 x 660 mm
ტექნიკური მახასიათებლები
- Total dimensions
- 2040/3000 mm
- Pressing power
- 4 x 2.5 t
- Bore distance, pressing unit
- 50
- Min. distance, pressing unit
- 240 mm
- Max. clamp height
- 1550 mm
- Net weight
- 220 kg
- Gross weight
- 260 kg
- EAN code
- 9120058371998
უპირატესობები
- Four 2.5 t pressing units with a self-holding function that keeps pressure through the cure
- Needs no electrical or compressed-air connection, so the VST3000 can stand anywhere
- 220 kg steel frame with 1550 mm clamp height takes tall stacked clampings
გასათვალისწინებელი
- Vertical pressure only - no horizontal units to hold wide panels flat
- Fully manual setting and clamping, so cycle time depends on the operator
- At 260 kg gross and 3030 mm packed, the VST3000 needs XL freight and real floor space
